Wholesale Engine Parts 232115 Diesel Fuel Filter FS19785 Fuel Water Separator for Fleetguard

Short Description:

Product Detail

Product Tags

Specifications

Shipment Height: 119.38 mm (4.7 in)
End 1 ID: 16.76 mm (.66 in)
Media Type: StrataPore
Largest OD: 88.82 mm (3.497 in)
End 2 OD: 88.39 mm (3.48 in)
Overall Height: 119.38 mm (4.7 in)

Details: Fuel Filter. For Housing use FH23200. Main Cross Reference is Davco 232115. Emulsified Water Separation: 95 % (95 %). Free Water Separation: 95 % (95 %). Efficiency TWA by SAE J 1985: 98.7 % (98.7 %). Micron Rating by SAE J 1985: 25 micron (25 micron). Fleetguard Part Type: FS. Comments: Diesel Pro FH232 Series. Stratapore Media 25 micron, 98% efficient at Free Water per SAE J1839 and 98% efficient at Emulsified Water per SAE J1488

How Does Fuel Filter Work?

A typical fuel filter consists of a filter medial and an inlet and outlet for the entry and exit of fuel. A fuel pump pushes fuel along the fuel lines at high pressure. This causes the fuel to move through the filter media forcefully. The filtration media is porous. Depending on the size of the pores, fuel flows through, while particles remain behind.

Some fuel filter types, specifically those in diesel engines, contain a mechanism to remove water from the fuel. Essentially, these filters contain a bowl at the bottom where the water that separates from fuel collects.

A drain valve allows for the emptying of the water bowl. These filters also come fitted with a water sensor to send a dashboard warning when the water needs to be drained from the bowl.

When Should A Fuel Filter Be Replaced?

A bad fuel filter requires replacing. While some people might try to fix a damaged filter by cleaning it, it may not be a good idea. Besides, most fuel filters are not costly devices. They also last a long time, and installing a new one cannot subject you to unhealthy expenses. How do you replace a bad fuel filter? The answer to that question is in the next chapter.
