Replace For John Deere Spin-on Lube Oil Filter RE541420

Short Description:


Product Detail

Product Tags

 Replace For John Deere Spin-on Lube Oil Filter RE541420

Quick details

Type:Fuel filter
MOQ:100pcs
Certification:ISO/TS16949
Sample:Available
Filtration Efficiency:Over 99.7%
Features:Filtering Efficiency
Shipment:On-time
Payment Protection:Yes
Delivery:7-15 Work Days
Business Type:Manufacturer and Exporter
Place of Origin:CN;ZHE
OE NO.:6005028743
OE NO.:Re541420
OE NO.:Re504836
Reference NO.:1 987 432 150
Reference NO.:AH7091
Reference NO.:732AC
Reference NO.:ALC5355
Reference NO.:BS02-005
Reference NO.:030787002
Reference NO.:1 987 431 150
Reference NO.:S3072C
Size:150.88*92.96 M92 X 2.5-6H INT
Warranty:1 year

Diesel filter

The structure of the diesel filter is roughly the same as that of the oil filter, and there are two types: replaceable and spin-on. However, its working pressure and oil temperature resistance requirements are much lower than those of oil filters, while its filtration efficiency requirements are much higher than those of oil filters. The filter element of diesel filter mostly uses filter paper, and some also use felt or polymer material.

Diesel filters can be divided into two types:
(1), diesel water separator
The important function of the diesel water separator is to separate the water in the diesel oil. The presence of water is extremely harmful to the diesel fuel supply system, and corrosion, wear, blockage and even worsen the combustion process of diesel. Engines with emissions above the national level III have higher requirements for water separation and require the use of high-performance filter media.

(2), diesel fine filter
The diesel fine filter is used to filter the fine particles in the diesel. Diesel engines with emissions above the national three are mainly aimed at the filtration efficiency of 3-5 micron particulate matter.

The principle of fuel filter?

The fuel filter is connected in series on the line between the fuel pump and the throttle body inlet. The function of the fuel filter is to remove solid impurities such as iron oxide and dust contained in the fuel and prevent the fuel system from being blocked (especially the fuel injector). Reduce mechanical wear, ensure stable engine operation and improve reliability. The structure of the oil burner consists of an aluminum casing and an internal stainless steel bracket. The holder is equipped with high-efficiency filter paper, which is in the shape of a chrysanthemum to increase the flow area. EFI filters cannot be used with carburetor filters
