Hydraulic filter 07063-01142
Size
Outer Diameter : 151mm
Height : 300mm
Inner diameter : 110mm
Inner diameter 1 : 110mm
OEM
CATERPILLAR : 3I1235
HYUNDAI : 34E702310
JCB : KRJ2780
KAWASAKI : 40338-20020
KOMATSU : 07063-01142
KOMATSU : 195-601-6320
KOMATSU : 7063-01142
KOMATSU : 7063-01412
KOMATSU : 7063-1142
KOMATSU : 7063-51142
Cross reference
BALDWIN : PT397
DONALDSON : P551142
FIL FILTER : ML 1163
FIL FILTER : ML 1163
FLEETGUARD : HF28975
FLEETGUARD : HF6356
FRAM : C7060
KOBELCO : 24046Z2
LUBERFINER : LH 8543
How to see the model of hydraulic oil filter?
Model example PALL filter element: HC8314FKN16H, what do the letters and numbers in this string mean?
We first divide it into five parts: HC is; 8314 is second; FKS is third; 16 is fourth; H is fifth.
1. HC: It means that the Pall filter element series filters hydraulic oil. Other filter series also include UE, HFU, etc.
2. 8314: Indicates the serial number of the Pall filter element. If the serial numbers are the same, then their inner and outer diameters are the same.
3. FKN: It needs to be disassembled for explanation here, F represents the oil filter element, K represents the filtration ratio ≥ 200 and there is a metal protective screen inside and outside, and the inside of the filter material has a non-metallic protective layer, N represents the filtration accuracy of 6μm.
a. There are two other letters used to indicate the filtration ratio of the filter element, one is D, the filtration ratio is ≥200 and there is a metal mesh inside and outside, the other is U, the filtration ratio is ≥75 and there is a metal mesh inside.
b. There are five other letters used to indicate the filtration accuracy of the filter element, namely Z=1μm, N=6μm, S=12μm, T=25μm, R=40μm, the Chinese unit is micron.
4, 16: Indicates that the height of the filter element is 16in, that is, the length of the filter element is 406.5mm. in is inches, the unit of length, 1in=25.4mm.
5. H: The seal of the filter element is NBR, the letter P means neoprene, the letter Z means fluorine rubber, and the letter J means ethylene or propylene.
