High Quality Diesel Fuel/Water Separator Filter Assembly FH230 with fuel filter FS19763

Short Description:

Send email to us

Product Detail

Product Tags

Specification

Height Overall 16.13″ (409.7 mm)

Depth Overall 7.25″ (184.15 mm)

Width, max 6.89″ (175 mm)

Mount Bracket Centers 5.91″ (150.11 mm)

Weight (Dry) 7.25 – 9.75 lbs (3.9 – 4.42 kg)

Fuel Connection (Inlet) 1/2″-14 NPTF (M22 x 1.5)

Fuel Connection (Outlet) 1/2″-14 NPTF (M22 x 1.5)

Fluid Heat Connection (Inlet) 1/2″ NPTF (M22 x 1.5)

Fluid Heat Connection (Outlet) 1/2″ NPTF (M22 x 1.5)

Fuel Capacity (w/ filter) 64.2 oz (1.9 L)

Operation Fuel Flow Rate 180 gal/hr (681 L/hr)

Recommended Applications Heavy Duty Engines

Water Trap Capacity 33.8 fl oz (1.0 L)

Filter Service Clearance Min. 1.5″ (38.1 mm)

Electrical Heater:
12 VDC, 250 W, 18 A ± 3 A
24 VDC, 250 W, 11 A ± 2 A
120 VAC, 75 W, 0.65 A ± .1 A

Fuel Types: Compatible for use with Diesel

High Performance, Low Stress

It is well known that water in diesel fuel can lead to extensive fuel system damage. Problems such as mechanical failures, biological growth in the fuel, and even frozen fuel lines during the winter months, can all be attributed to water in diesel fuel. The FH230 Series filter element is a fuel/water separator that removes both water and contamination from your fuel prior to entering the fuel pump.
you can see conveniently when it is time to service the unit and change out filter elements. Simply separate water from the fuel and collect at the bottom where it can be drained. As the filter saturates with contaminants, the fuel level will gradually rise to the black band at the top of the element to indicate that it’s time to replace the filter…no more guessing!

Replated proructs

Fleetguard FH230 Fuel Pro Series Fuel Separator
Installed on trucks, vans and jeeps.
FH 230 Fuel Pro up to 680 l / h.
FH23067M – Fleetguard FH23067M Filter Separator
FH23068M – Filter Separator FH23068M Fleetguard
FH23069M – Filter Separator FH23069M Fleetguard
FH23054 ← FH23001 – Filter Separator FH23001 Fleetguard
FH23027 – Filter Separator FH23027 Fleetguard
FH23028 – FH23028 Fleetguard Separator Filter
FH23029 – Filter Separator FH23029 Fleetguard
FH23030 – Filter Separator FH23030 Fleetguard
FH23031 – Filter Separator FH23031 Fleetguard
FH23032 – Filter Separator FH23032 Fleetguard
FH23038 – FH23038 Fleetguard Separator Filter
FH23039 – Fleetguard FH23039 Separator Filter
FH23040 – Filter Separator FH23040 Fleetguard
FH23041 – Fleetguard FH23041 Separator Filter
FH23042 – Filter Separator FH23042 Fleetguard
FH23045 – Filter Separator FH23045 Fleetguard
FH32049 – Filter Separator FH23049 Fleetguard
FH23050 – Filter Separator FH23050 Fleetguard
FH23054 – Filter Separator FH23054 Fleetguard
FH23060 – Filter Separator FH23060 Fleetguard
FH23061 – Filter Separator FH23061 Fleetguard
FH23076 – Filter Separator FH23076 Fleetguard
FH230 – Filter separator FH230 LOCKHEED
FH23070 – Filter separator FH23070 FLEETGUARD
FH23072GM – Filter separator FH23072GMFLEETGUARD
