Fuel filter water separator FS1006 fuel filter 3089916 4759205

Short Description:

Send email to us

Product Detail

Product Tags

Size

Outer Diameter : 116mm

Inner diameter 1 : 98mm

Inner diameter 2 : 111mm

Height : 313mm

Outlet Thread Size : 1 1/4-12 UNS

OEM

CUMMINS : 3089916

CUMMINS : 33 09 437

CUMMINS : 4095189

EUCLID : E4084262

HITACHI : 4202934

HITACHI : 4446815

HITACHI : 4640732

HITACHI : L4202934

KOMATSU : 3313304

KOMATSU : 600-311-3110

KOMATSU : 600-311-3111

KOMATSU : 600-311-7550

KOMATSU : 600-319-3111

KOMATSU : BF4803

LIEBHERR : 5617911

LIEBHERR : 736 4590

PERKINS : 4759205

SISU : 1273 400331

TEREX : 15267633

VOLVO : 4084262

Cross reference

BALDWIN : BF1262

DONALDSON : P551006

DONALDSON : P552006

DONALDSON : P552216

FLEETGUARD : FS1006

FLEETGUARD : FS1216

FLEETGUARD : FS19870

GUD FILTERS : Z 369

JS ASAKASHI : FS1006

LUBERFINER : LFF 1021

MANN-FILTER : WK 12 290

An oil-water separator assembly belongs to the technical field of filtering devices, comprising a filter element and a filter seat, a filter channel is arranged in the upper part of the filter element, and a drainage channel is arranged in the middle and lower part of the filter element, and is characterized in that a double-ended hollow bolt is arranged in the filter seat, and the filter element and the filter element are provided with a filter channel. The seats are threadedly connected by double-ended hollow bolts, and the middle of the double-ended hollow bolts is provided with an oil hole, which is communicated with the oil inlet valve set on the filter seat, and the top of the double-ended hollow bolt is connected with the oil outlet set on the filter seat. The holes are connected, an oil outlet valve is also arranged on the channel between the oil inlet valve and the oil outlet hole, and a manual pump is arranged on one side of the filter seat to locate and control the oil inlet valve and the oil outlet valve. In the abnormal working condition that the engine cannot supply oil, the manual pump is used to supply oil, and the fuel is filtered through the filter element to prevent moisture and particulate impurities from directly entering the engine, which will seriously affect the engine work, improve the high-pressure common rail fuel injection quantity and Precise control of injection, increase the service life of fuel injectors, convenient maintenance, and improve the flexibility of use.

A fuel filter assembly for oil-water separation, comprising a filter element (2) and a filter seat (6), a filter channel is arranged in the upper part of the filter element (2), and a water discharge channel is arranged in the middle and lower part of the filter element (2), and is characterized in that the filter element (2) is A double-ended hollow bolt (3) is arranged in the seat (6), the filter element (2) and the filter seat (6) are threadedly connected by a double-ended hollow bolt (3), and an oil hole (4) is provided in the middle of the double-ended hollow bolt (3). ), the oil passage hole (4) is communicated with the oil inlet valve (10) provided on the filter seat (6), and the top of the double-ended hollow bolt (3) is connected with the oil outlet hole (5) provided on the filter seat (6). ) are connected, an oil outlet valve (8) is also provided on the channel between the oil inlet valve (10) and the oil outlet hole (5), and a manual pump (9) is arranged on one side of the filter seat (6) for positioning and controlling the inlet and outlet. The oil valve (10) and the oil outlet valve (8) work.
