Factory Mopar Diesel Fuel and Oil Filter Set For Ram 2500 3500 4500 5500 5083285AA
Factory Mopar Diesel Fuel and Oil Filter Set For Ram 2500 3500 4500 5500 5083285AA
Quick details
Outer diameter 93 mm (3.66 inches)
Thread Size 1-16 UN
Length 174 mm (6.85 inches)
Gasket OD 72 mm (2.83 in)
Gasket ID 62 mm (2.44 in)
Filtration efficiency 99% 40 microns
Filtration Efficiency Test Standard SAE J 1858
Filter Type Cellulose
Blasting 6.9 bar (kg/cm2) (100 psi)
Model Full Flow
Style Spinning
Main Application Cummins 3932217
Package dimensions
Overall length 9.398CM
Overall width 9.398 cm
Overall height 17.526 cm
Total weight 0.7333333 kg
Total volume 0.00224 M3
Material:
Filter paper (filter): oil paper
Sealing ring: high quality nitrile rubber
Application: light truck
Ram 1500 2004, 1998-2001 6 Cyl 5.9L Diesel, 6 Cyl 6.7L Diesel
Ram 2500 2004-2010, 1998-2002 6 Cyl 5.9L Diesel, 6 Cyl 6.7L Diesel
Ram 3500 2004-2010, 1998-2002 6 Cyl 6.7L Diesel
Ram 4500 2009-2010 6 Cyl 6.7L Diesel
Ram 5500 2008-2010 6 Cyl 6.7L Diesel
Ram 2500 2011-2017 6 Cyl 6.7L Diesel
Ram 3500 2011-2017
Ram 4500 2011-2017 6 Cyl 6.7L Diesel
Ram 5500 2011-2017 6 Cyl 6.7L Diesel
product manual
oil filter
located in the engine lubrication system. Its upstream is the oil pump, and downstream is the various parts in the engine that need to be lubricated.
Its function is to filter the harmful impurities in the machine oil from the oil pan, and supply the crankshaft, connecting rod, camshaft, supercharger, piston ring and other moving pairs with clean oil, which plays the role of lubrication, cooling and cleaning. , thereby extending the life of these components.
Fuel Filter
Its function is to filter out harmful particles and moisture in the engine fuel gas system to protect the oil pump nozzle, cylinder liner, piston ring, etc., reduce wear, and avoid clogging. Remove the iron oxide, dust and other solid impurities contained in the fuel to prevent the fuel system from being blocked (especially the fuel injector). Reduce mechanical wear, ensure stable engine operation and improve reliability.
air filter
Located in the engine air intake system, it is an assembly of one or several filter components that clean the air. Its main function is to filter out harmful impurities in the air that will enter the cylinder, so as to reduce the early wear of the cylinder, piston, piston ring, valve and valve seat.
