factory direct sale 24520728 replacement Ingersoll Rand air compressor spare parts oil separator filter cartridge

Air compressor oil water separation filter element

The working principle of the filter element:
​​
When the compressed air containing oil and water and other gases are passed into the oil-water separator, the large droplets fall to the bottom of the oil-water separator under the action of gravity, and the mist-like small droplets are captured by the wire mesh and condense into large droplets and fall to the bottom of the oil-water separator. The entrained liquid is thus separated, and the separated liquid flows into the lower part and is discharged by manually opening the valve or installing an air drain valve in the lower part to discharge the body, and the dry and clean gas is discharged from the outlet of the oil-water separator.
​​
1. The oily sewage is sent to the oil-water separator by the sewage pump. After passing through the diffusion nozzle, the large oil droplets will float on the top of the left oil collecting chamber.
​​
2. The sewage containing small oil droplets enters the corrugated plate coalescer in the lower part, where the oil droplets are aggregated into larger oil droplets to the right oil collecting chamber
​​
3. The sewage containing oil droplets with smaller particles passes through the fine filter to remove impurities in the water, and then enters the fiber aggregator in turn, so that the small oil droplets are aggregated into larger oil droplets and separated from the water.
​​
4. After separation, the clean water is discharged through the discharge port, the dirty oil in the left and right oil collecting chambers is automatically discharged by the solenoid valve, and the dirty oil separated in the fiber aggregator is discharged by the manual valve.
