Alternatives to ATLAS COPCO Air compressor accessories 1613692100

Quick details

Application:Air Filtration
Type:Press Filter
Structure:Cartridge
Filtration Precision:1~100 Micron
working system:hydraulic and fuel system
Filter material:Superior glass fiber/Stainless steel
Type:Air compressor accessories

When do we need to replace the filter element of the air compressor?

The same is true of the air compressor during use. The dust in the air sucked by the air compressor during use is blocked in the filter to avoid premature wear of the compressor and blockage of the oil separator, usually after 1000 hours of operation or a year, the filter element should be replaced , in dusty areas, the replacement interval should be shortened.

When the consumption of lubricating oil of the air compressor increases greatly, check whether the oil filter, pipeline, oil return pipe, etc. are blocked and cleaned. If the oil consumption is still large, the general oil and gas separator has deteriorated and needs to be replaced in time; when When the pressure difference between the two ends of the oil and gas separation filter element reaches 0.15MPA, it should be replaced; when the pressure difference is 0, it indicates that the filter element is faulty or the air flow has been short-circuited, and the filter element should be replaced at this time. The general replacement time is 3000~4000 hours. If the environment is poor, the use time will be shortened.

How to replace the filter element?

External model
The external model is relatively simple, the air compressor is stopped, the air pressure outlet is closed, the drain valve is opened, and the old oil and gas separator can be removed and replaced with a new one after confirming that there is no pressure in the system.
1. Facing a flat surface, tap the two end faces of the filter element in turn to remove most of the heavy and dry dust.
2. Blow with dry air less than 0.28Mpa in the opposite direction to the inhaled air. The distance between the nozzle and the folded paper is 25mm, and blow up and down along its height direction.
3. Check the filter element. If any thinning, pinhole or damage is found, it should be discarded.
Built-in model
Properly replace the oil and gas separator as follows:
1. Shut down the air compressor, close the air pressure outlet, open the drain valve, and confirm that the system has no pressure.
2. Disconnect the pipeline above the oil and gas tank, and at the same time remove the pipeline from the outlet of the pressure maintenance valve to the cooler.
3. Remove the oil return pipe.
4. Remove the fixing bolts of the cover on the oil and gas tank, and remove the upper cover of the gas tank.
5. Remove the oil and gas separator and replace it with a new one.
6. Install in the reverse order of disassembly.
