Air filter for aftermarket replace AF4674 AF4675

Short Description:

Send email to us

Product Detail

Product Tags

AF4674

Size

Outer diameter 1: 316mm

Outer diameter 2: 316mm

Inner diameter 1: 191.5mm

Inner diameter 2: 11.5mm

Height 1: 682.75mm

Height 2: 673mm

Filter Insert

OEM

CUMMINS : 3060220

GENERAL MOTORS : 25313770

MAN : 64.08301-0005

MAN : 64.08304-0005

ONAN : 1402409

Cross reference

BALDWIN : PA2744

CARQUEST : 88866

DONALDSON : P546614

FLEETGUARD : AF26084

FLEETGUARD : AF4674

FRAM : CA7699

GARDNER PARTS : 2117324

MAHLE : LXS7225200914

AF4675

Size

Outer diameter 1: 190mm

Outer diameter 2: 190mm

Inner diameter 1: 158mm

Inner diameter 2: 17mm

Height 1: 652.7mm

Height 2: 640mm

Filter Insert

OEM

GENERAL MOTORS : 25313771

MAN : 64.08304-0002

MAZDA : CD1628610827

ONAN : 1402410

Cross reference

BALDWIN : PA2745

CARQUEST : 88856

DONALDSON : P546613

FLEETGUARD : AF26083

FLEETGUARD : AF4675

What is the usage of air filter?

The function of the air filter is mainly to filter impurities or dust in the air and let clean air enter the cylinder. Practice has proved that the life of engine without air filter will be shortened by 2/3. In addition, the air filter can also reduce the intake noise. The air filter is located in the engine air intake system. It is an integral mechanism composed of one or several clean air filter components. There are two types of air filters; Dry and wet.
The structure of the air filter is very simple, that is, there is a metal or paper filter element in a housing (paper filter elements are often used), and when air flows through it, impurities will be blocked and adhered to the filter element. The utility model has the advantages of simple structure, convenient maintenance and small intake resistance; The disadvantage is that the filtering effect is limited. If the air filter is damaged, the dust will directly enter the engine.

3. Due to the harsh working environment of heavy vehicles, their air filters must be majority. The first stage is a swirling pre filter (such as blade ring, swirling tube, etc.), which is used to filter out coarse particles and impurities. The filtering efficiency is more than 80%. The second stage is a microporous paper filter element (generally called the main filter element), with a filtering efficiency of more than 99.5%. There is also a safety filter element behind the main filter element, which is used to prevent dust from entering the engine when installing and replacing the main filter element, or when the main filter element is accidentally damaged. The material of the safety core is mostly nonwoven, and filter paper is also used.
